Product Introduction
In chemical laboratories, harmful gases, odors, moisture, and corrosive substances are generated during experiments. To ensure user safety and prevent the spread of pollutants, a fume hood must be installed near contamination sources.
Key Features
1. Cabinet Material: Constructed with 8mm thick acid/alkali-resistant, chemical-proof, impact-resistant white PP panels using seamless welding. Resistant to strong acids, alkalis, corrosion, and rust-proof.
2. Work Surface Options: Available in solid-core phenolic resin board, PP panel, or ceramic panel.
3. Ergonomic Design: 30° inward-sloped front/side panels with seamless welding. Optional water/gas faucets, sinks, and control valves. Auxiliary air intake for airflow compensation when the sash is closed.
4. Internal Structure: 8mm PP liner with airtight welding. Three-tier baffle system ensures complete exhaust of gases with varying densities.
5. Safety Glazing: 5mm tempered glass view window with PVC frame and stainless-steel reinforced sliding tracks for smooth, quiet operation.
6. Full-PP Construction: All interior components made of PP with welded joints, ensuring durability in extreme acidic/alkali environments.
7. Control System: Integrated panel for lighting, circuits, and airflow adjustment.
8. Specialized Outlets: Lab-grade 10A/16A triple-purpose sockets with dust/acid/water resistance.
Technical Specifications
External Dimensions: ≥1247×800×2450mm (L×D×H)
Internal Dimensions: ≥987×560×700mm (L×D×H)
Work Height: 820mm from bench to floor
Inlet Airflow: 0.3–0.8m/s
Exhaust Capacity: 700m³/h
Rated Power: 400W (excludes socket load, max 500W)
Noise Level: ≤68dB(A)
Illuminance: ≥400lx
Sash Opening Height: 740mm
LED Lighting: 24W (2×12W tubes)
Blower Specifications: 300W
Weight: Upper cabinet 154.3kg / Lower cabinet 98.7kg
User Capacity: 1–2 operators
