Reverse Osmosis Industrial Water Treatment Systems 500LPH

Our main water treatment technology is Reverse Osmosis (RO) water treatment system. Which is that raw water passes through reverse osmosis membrane under high pressure, and the solvent in water diffuses from low concentration to high concentration to achieve the purpose of separation, purification and concentration. Reverse osmosis water treatment system can remove bacteria, viruses, colloid, organic matter and more than 99% soluble salts in water. The equipment has the characteristics of low operation cost, simple operation, high automation degree and stable effluent quality. Compared with other traditional water treatment methods, it has obvious advantages and is widely used in water treatment related industries.

Parameter

Flow Chat

raw water(city water)→ raw water tank→ raw water booster pump→ quartz sand filter→ carbon filter→ water softener (optional)→ security filter→ high pressure water pump→ reverse osmosis unit→ pure water tank→ pure water

Pretreatment:

(1) Quartz sand/manganese sand filter;
(2) Activated Carbon filter;
(3) Softener and PP Filter ;
(4) Dosing system if need.

Main Machine of Water Treatment:

(1) Pumps;

(2) RO membrane (DOW/CSM/Hydranautics);

(3) Membrane Vessel(SS and FRP);

(4) PLC control/Relay control;

(5) Optional UV sterlilizer&Ozone.

Working Process

1. Raw water booster pump-- provide the pressure to quartz sand filter/active carbon filter.
2. Multi-medium filter--get rid of turbidity, suspended matter, organic matter, colloid, ect.
3. Carbon filter--Remove the color, free chloride, organic matter, harmful matter, ect.
4. Water softener--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,
6. High pressure water pump--Provide the high pressure to RO membrane ro.
7. Reverse osmosis unit-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.

Applications

Widely used in various industrial sectors.

water fillers

First stage pretreatment.(Sand filter) The use of multi-medium quartz sand filters, main purpose is to remove the water contains sediment, manganese, rust, colloid material, mechanical im
